Rotary Back-Blowing Baghouse Dust Collector

Name: Rotary Back-Blowing Baghouse Dust Collector
Brand: Chity
SKU: 18503776
Rating: 4.75 (10 reviews)

Categories	Baghouse Dust Collector
Brand	Chity
Model	Rotary Back-Blowing Clean Type
Material of Shell	Usually Carbon Steel
Thickness of Shell	3mm/4mm/5mm
Material of Filter Bag	Usually Polyester
Material of Filter Cage	Usually Carbon Steel
Certification of Motor	CE/CSA/UL/ATEX
Discharge Valve	Rotary Airlock/Gate Valve/Heavy Hammer Flap Valve
Control Panel	Touch Screen/Button/PLC Remote
Download
Update Time	Apr 4,2025

Contact Now

Favorites

Detail Information

Introduction

Rotary back-blowing dust collector is an efficient industrial filtration system designed for continuous dust removal. It features a rotating back-blowing mechanism that periodically cleans filter bags using reverse airflow, preventing dust buildup and ensuring stable performance. Unlike pulse jet valves, it operates without compressed air, reducing energy consumption and maintenance costs. This system offers high filtration efficiency, low noise operation, and long filter life, making it ideal for industries such as metallurgy, chemicals, and food processing. Its compact and durable design allows for easy installation and long-term reliability. By effectively controlling dust emissions, the rotary back-blowing dust collector improves workplace air quality and ensures environmental compliance. Suitable for handling fine and sticky dust, it provides a cost-effective and sustainable dust control solution for various industrial applications.

Key Features

>Rotary Back-Blowing Mechanism – Cleans filters using reverse airflow instead of compressed air, preventing dust buildup.

>Energy Efficient – Operates without compressed air, reducing energy consumption and no need for air compressor.

>High Filtration Efficiency – Effectively captures fine and sticky dust particles.

>Lower Maintenance – Minimal maintenance required, lowering operating costs.

>Compact Design – Space-saving and easy to install in various industrial settings.

>Durable Construction – Built for long-lasting performance in demanding environments.

>Low Noise Operation – Operates quietly, reducing noise pollution in the workplace.

>Environmental Compliance – Controls dust emissions, ensuring a safer, cleaner workplace.

Components

>Filter Bags – PE/PP/PPS/PTFE/Nomex/Fibergalss filter bags can be choosed for different conditions, usually polyester filter bags.

>Filter Cages – Carbon steel, 304 or 316L material can be choosed, usually carbon steel is enough.

>Rotary Back-Blowing System – A rotating mechanism that directs reverse airflow to clean filter bags by dislodging accumulated dust.

>Rotary Arm Mechanism – A rotating arm with air nozzles that moves over the filter bags, directing reverse airflow to dislodge dust.

>Dust Hopper – A conical container at the bottom of the dust collector that collects and stores dislodged dust before discharge.

>Airlock Valve (Rotary Valve) – A discharge valve, often a rotary airlock valve, that prevents air leakage while allowing dust removal from the hopper.

>Induced Draft Fan – Generates suction to pull dust-laden air into the dust collector and push clean air out.

>Control Panel – A device that monitors and controls the operation of the dust collector, including the fan, cleaning system, and alarms for maintenance needs.
